Professional Plastic Extrusion Machine , HDPE / PE Water Pipe Making Machine

dobra jakość Linia wytłaczania rur z tworzyw sztucznych na sprzedaż
dobra jakość Linia wytłaczania rur z tworzyw sztucznych na sprzedaż
This machine is very good , and the after-saes service is good. The pvc board machine is easy to operate and the output is stable

—— Nancy

The pvc board extrusion machine is good quality , it is beautiful and the output is stable , this is a reliable company

—— Albert

Im Online Czat teraz

Professional Plastic Extrusion Machine , HDPE / PE Water Pipe Making Machine

Chiny Professional Plastic Extrusion Machine , HDPE / PE Water Pipe Making Machine dostawca
Professional Plastic Extrusion Machine , HDPE / PE Water Pipe Making Machine dostawca Professional Plastic Extrusion Machine , HDPE / PE Water Pipe Making Machine dostawca Professional Plastic Extrusion Machine , HDPE / PE Water Pipe Making Machine dostawca Professional Plastic Extrusion Machine , HDPE / PE Water Pipe Making Machine dostawca

Duży Obraz :  Professional Plastic Extrusion Machine , HDPE / PE Water Pipe Making Machine

Szczegóły Produktu:

Place of Origin: ShanDong China
Nazwa handlowa: AORUI
Orzecznictwo: CE UL CSA
Model Number: SJ45/33

Zapłata:

Minimum Order Quantity: 1 set
Cena: Negotiable
Packaging Details: Fumigationwood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 10 sets per month
Contact Now
Szczegółowy opis produktu
Payment terms: TT or L/C Certificate: CE ISO9001
Product type: PE Pipe Nazwa handlowa: Aorui
Condition: New Temperature controller: Omron
Motor: Siemens Port: Qingdao

Plastic PE Water Pipe Making Machine , PE Drain Water Pipe Production Line


Quick detail:

1. Our engineers and technicians have more than 10 years experince in this field. With CE standard and rich experince, Sunrise Machinery will be your reliable supplier for plastic machines. We warmly welcome friends from all over the world to visit our factory.



2. Good design and good outlook: We design the machine for easier operation and stable performance. The haul off machine and cutter is fully closed for safety purpose. Planetary socket is using in some machines for wire connection.





Description:

1. This PE pipe extrusion line can be used in HDPE Large Diameter Gas and Water Pipe which have excellent stiffness and flexibility, heat resistance, aging resistance, high mechanical strength, resistance of environmental stress cracks, resistance to creep deformation, heat-linkage, and so on. So, it is a preferred gas and water pipe for ductwork system between city and its suburb, Large diameter HDPE pipes start to play very important role in the city water and gas supply systems.

2. Process Flow
Raw material + additive → mixing → vacuum feeding machine → hopper dryer → single screw extruder → color code extruder → mould and calibrator → vacuum forming machine → cooling tank → haul off machine → cutting machine → stacker



3. Characteristics
1, The extrusion line produces PP, PE ,PPR, ,HDPE ,LDPE and water pipe.
2, The unit consists of single screw extruder, vacuum calibration tank, haul-off, cutter and stacker etc.
3, This line is of reliable performance and high production efficiency.
4, Our company can also manufacture PVC pipe extrusion line,UPVC pipe extrusion line etc.



Main Technical Parameters



Model
PE-16/63

PE-20/110

PE-50/160

PE-75/250

PE-110/315

PE-200/450

PE-315/630

PE-400/800

Pipe diameter

16-63mm

20-110mm

50-160mm

75-250mm

110-315mm

200-450mm

315-630mm

400-800mm

Max output

150kg/h

200kg/h

300kg/h

350kg/h

400kg/h

500kg/h

850kg/h

850kg/h

Extrusion speed

1-15m/min

1.2-12m/min

0.6-8m/min

0.5-4m/min

0.4-3.7m/min

0.3-3m/min

0.2-2m/min

0.1-1 m/min

Extruder model

SJ-65/30

SJ-65/33

SJ-75/33

SJ-75/33

SJ-75/33

SJ-90/33

SJ-120/33

SJ-120/33

Installed power

85kw

110kw

125kw

180kw

260kw

325kw

480kw

600kw

Center height

1000mm

1000mm

1000mm

1000mm

1100mm

1100mm

1200mm

1300mm

Line length

35m

38m

38m

40m

42m

52 m

60m

68m






FAQ:


Q1:Are you a trading company or a manufactory? A1:We are a manufactory,so we can give u the best service .
Q2:What's your guarantee or the warranty of the quality if we buy your machines? A2:We offer you high quality machines with 1 years guarantee . we will give you spare part free in 1 years
Q3:When can I get my machine after I paid? A3:We will deliver the machines on time as the date we agreed both side.
Q4:How can I install my machine when it arrives? A4:We will send our engineer to your side as soon as you get all your machines ready , for testing and teaching your technicians how to run the machines.
Q5:How about the spare parts? A5:After we deal down all the things , we will offer you a spare parts list for your reference.
