Waterproofin / Fire Retardant PVC Foam Board Machine PET Sheet Extrusion Line

Chiny Waterproofin / Fire Retardant PVC Foam Board Machine PET Sheet Extrusion Line dostawca
Waterproofin / Fire Retardant PVC Foam Board Machine PET Sheet Extrusion Line dostawca Waterproofin / Fire Retardant PVC Foam Board Machine PET Sheet Extrusion Line dostawca Waterproofin / Fire Retardant PVC Foam Board Machine PET Sheet Extrusion Line dostawca Waterproofin / Fire Retardant PVC Foam Board Machine PET Sheet Extrusion Line dostawca

Duży Obraz :  Waterproofin / Fire Retardant PVC Foam Board Machine PET Sheet Extrusion Line

Szczegóły Produktu:

Place of Origin: China
Nazwa handlowa: AORUI
Orzecznictwo: CE UL CSA ISO9001
Model Number: SJSZ65/132

Zapłata:

Minimum Order Quantity: One set
Cena: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C Western Union
Supply Ability: 10 Sets per month
Contact Now
Szczegółowy opis produktu
Warranty: 12 months Product thickness: 1-30mm
Screw & Barrel material: 38Cr MOAIA Port: Qingdao
Condition: New Automatic grade: Fully automatic
Certificate: CE ISO9001 Power: 37kw

PVC Free Foamed Board Production Line , PVC WPC Decoration Sheet Making Machines





Quick detail:



1. PVC Free Foam Sheet / PVC Free Foam Board is the new man-made material, the main component is PVC, it has the fine chemical stability, anti-corrosive and high intensity, it can be the substitute of wood, it is widely used in the building, advertisement and decoration.



2. Features:
1. Waterproofing.
2. Fire retardant and self-extinguishing.
3. Heat preservation.
4. Sound-insulated.
5. Insulation.
6. Non-corrosion.
7. Non-toxic.
8. Tough, rigid with the high impact strength.
9. Stable color retention.









Description:



1. This PET sheet extrusion line is equipped three-roller calander, with high performance vented extruder, die, screen change system, cooling rocket, haul-off unit, cutting unit and etc. specially designed for producing APET, PETG and CPET single-layer and multi-layer sheet with thickness of 0.12mm to 5 mm and width of 500mm to 3000mm. It can be for produce PS,PP and PE sheet also.



2. Cooling system of screw core uses constant temperature system controlled by hot oil, so that material can be plastified well; And barrel uses vacuum exhaust type, so that moisture content can volatilize fully and keep product quality.
Driving by DC motor with advantages of steady output and large torque, and it also uses ABB or England Eurotherm speeder with the advantages of large extrusion quantity and high-efficiency.



3. Using international advanced CAD design software, 38CrMoAIA alloy steel with superior quality and coating metal on surface, special mixing material function and high plastify of screw and barrel.










Applications:



1. Building outdoor wall board, indoor decoration board, partition board in office and house.
2. Screen printing, flat solvent printing, engraving, billboard and exhibition display.
3. Chemical anticorrosion project, special cold project, environmental protection.





Specifications:



Model BDX-1220 BDX1830
No Parts Parameter Parmeter
1 Mixer Loader 1.5kw 3
2 Mixer SRL300/600 SRL500/1000
3 Spring Loader Spring type 3KW
4 Extruder SJSZ80/156 SJSZ92/188
5 Mould 1220MM 1830MM
6 Tem-controler 50-160°c 50-160°c
7 Board forming machine Plate : 4* 1500mm Plate: 5 * 2000mm
8 Air cooling bracket 10m 10mm
9 Hauling off unit 1500mm width 2000mm width
10 Cutting unit 3KW 5.5kw
11 Dust vacuuming unit 5.5KW 5.5kw
12 Stacker 5 Rollers 7rollers
13 Control Box ABB Siemens,RKC,Schneider,NSK ETC





Competitive Advantage:



1) We give you suitable suggestions according to your actual need.
2) Technical support: available lifelong
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.



Waterproofin / Fire Retardant PVC Foam Board Machine PET Sheet Extrusion LineWaterproofin / Fire Retardant PVC Foam Board Machine PET Sheet Extrusion Line
