800mm Single Screw PE Pipe Making Machine , Plastic Pipe Production Line

dobra jakość Linia wytłaczania rur z tworzyw sztucznych na sprzedaż
dobra jakość Linia wytłaczania rur z tworzyw sztucznych na sprzedaż
This machine is very good , and the after-saes service is good. The pvc board machine is easy to operate and the output is stable

—— Nancy

The pvc board extrusion machine is good quality , it is beautiful and the output is stable , this is a reliable company

—— Albert

Im Online Czat teraz

800mm Single Screw PE Pipe Making Machine , Plastic Pipe Production Line

Chiny 800mm Single Screw PE Pipe Making Machine , Plastic Pipe Production Line dostawca
800mm Single Screw PE Pipe Making Machine , Plastic Pipe Production Line dostawca 800mm Single Screw PE Pipe Making Machine , Plastic Pipe Production Line dostawca 800mm Single Screw PE Pipe Making Machine , Plastic Pipe Production Line dostawca

Duży Obraz :  800mm Single Screw PE Pipe Making Machine , Plastic Pipe Production Line

Szczegóły Produktu:

Place of Origin: ShanDong China
Nazwa handlowa: AORUI
Orzecznictwo: CE & ISO9001
Model Number: SJ65/33

Zapłata:

Minimum Order Quantity: 1 set
Cena: Negotiable
Packaging Details: Fumigation wood, film,pallet,etc or according to customer’s requirement.
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 30 sets per quarter
Contact Now
Szczegółowy opis produktu
Raw material: PE Certificate: CE&ISO9001
Screw Design: Double Screw Output: 120-800kg
Application: Water pipe Inverter: ABB
Color: according to customer's requirement Automatic grade: Fully automatic

800mm Single Screw PE Pipe Making Machine , Plastic Pipe Production Line





Quick detail



1. Pipes made from PE are usually manufactured by extrusion.This process starts by feeding plastic material from a hopper into the barrel of the extruder.The material is gradually melted by the mechanical energy generated by turning screws and by heaters arranged along the barrel.The molten polymer is then forced into a die,which shapes the polymer into a pipe that hardens during cooling.



2. PE pipe production line mainly consists of extruder, vacuum calibration tank, haul-off unit, cutter, stacker etc.




Description:



1. Installed with imported termo controllers, imported inverters or converters. Hardened gear reducer box, carburized and grinded teeth, installed with forced cooling system to ensure high-performance, low noise and long service life. For the material feeding section of barrel there're slotted bushing and smooth grooves, two designs to meet the needs of different raw materials. Screw and barrel made of nitrided 38CrMoALA wear resistant, corrosion resistant, high strength. We also can provide a variety of exhaust-type extruder.



2. We are an industrial manufacture factory. We have independent technical team who focus on making machines, all the products are made by our technical team.



3. This machine is mainly used to produce agricultural/water supply pipes, gas supply pipes, architectural water supply/drainage pipes, cable laying pipes etc. This PP PE pipe making machine adopts advanced design concept to ensure the efficient extrusion of PP,PE material combined with the unique concept of plasticization screw design to ensure uniformity of plastic extrusion, high capacity production.






Application:





  The production line is mainly used to manufacture for PE plastic pipe, and GF serirs tube auxiliary equipment production line can also be used to produce other plastic, Extruder and GF series tube auxiliary equipments production line take the features of advantages ,reliability and applicability together, and provide strong certification for high-quality plastic tube for customers.







Main Technical Parameters





Model
PE-16/63

PE-20/110

PE-50/160

PE-75/250

PE-110/315

PE-200/450

PE-315/630

PE-400/800

Pipe diameter

16-63mm

20-110mm

50-160mm

75-250mm

110-315mm

200-450mm

315-630mm

400-800mm

Max output

150kg/h

200kg/h

300kg/h

350kg/h

400kg/h

500kg/h

850kg/h

850kg/h

Extrusion speed

1-15m/min

1.2-12m/min

0.6-8m/min

0.5-4m/min

0.4-3.7m/min

0.3-3m/min

0.2-2m/min

0.1-1 m/min

Extruder model

SJ-65/30

SJ-65/33

SJ-75/33

SJ-75/33

SJ-75/33

SJ-90/33

SJ-120/33

SJ-120/33

Installed power

85kw

110kw

125kw

180kw

260kw

325kw

480kw

600kw

Center height

1000mm

1000mm

1000mm

1000mm

1100mm

1100mm

1200mm

1300mm

Line length

35m

38m

38m

40m

42m

52 m

60m

68m





Our comapny competitive:



  • 24 hours services;
  • Overseas installation;
  • Free operation training and technology formula transfer;
  • Old machine update;
  • Spare parts and maintenance with reasonable cost price.
